Volvo Dd14 dd16 Asphalt
Introducing reliable performance in a smaller package, Ingersoll Rand combined our global engineering resources to bring you the DD-14 and DD-16 vibratory asphalt compactors. Offering high productivity and unsurpassed value, these machines feature industry-leading drum performance, superior propulsion characteristics, and unmatched operation intervals in a class-leading 2.5-tonne machine.
Designed for optimum compaction of complex materials, the DD-14 and DD-16 provide high performance in a small package. Move your business and bottom line in the right direction with the Dd14 dd16.
Volvo Dd14 dd16 Asphalt Factory Service Repair Manual
PERFORMANCE FEATURES
PERFORMANCE FEATURES
■ Drum performance
– High 4,000 vpm frequency for consistent smoothness
– Operator can choose front-drum vibration only,
double-drum vibration, or static mode
– Machined / chamfered drum edges
■ Industry-leading water system
– 52 gal (197 L) water tank extends refill intervals
– Standard pressurized water system, handserviceable
nozzles, and double-filtration
– Water flows only when the compactor is
moving (in automatic mode)
■ Operations
– High curb and low side clearances allow for
efficient maneuvering around jobsite obstacles
– Isolation of the vibratory drum and operator
platform enhances operator comfort and safety
– Propulsion and vibration controls are conveniently
designed for comfort, simplicity, and ease of use
– Back-up alarm is standard equipment
■ Serviceability
– Unobstructed daily checkpoints, easy-to-lift engine
enclosure, plus ground-level access to the engine,
radiator, battery, and filters
– Color-coded service charts show detailed
checkpoints, service intervals, and proper lubricants
