New Holland EC15, EC25, EC35, EC45 Mini Excavator Service Manual

Table of content (Service Manual)

SECTION 00 – GENERAL INFORMATION
SECTION 6 – ELECTRICAL SYSTEM
SECTION 7 – HYDRAULIC SYSTEM
SECTION 10 – OPERATORS PLATFORM
SECTION 11 – TRACTION/UNDERCARRIAGE

Instructions

This manual covers the repair and adjustment procedures for the New Holland Model EC15, EC25, EC35, EC45 Mini Excavator. All repair and maintenance work listed in this manual must be carried out only by qualified personnel, strictly complying with the instructions given, and using, whenever possible, the special tools.

Thoroughly read and understand this Service manual and the Operators Manual before operating any repair or servicing.

For easy references the manual is breakdown in several chapter with an easy to follow instruction for repairing guidance of the different part of the Excavator.

MODEL ENGINE TYPE – HORSEPOWER
EC15 Mitsubishi L3E four-stroke diesel engine – 17.8 hp
EC25 Mitsubishi S4L- 61KL four-stroke diesel engine – 27.5 hp
EC35 Mitsubishi S4L-2-61KL four-stroke diesel engine – 35.5 hp
EC45 Mitsubishi S4Q2-61KL four-stroke diesel engine – 46.4 hp

New Holland EC15, EC25, EC35, EC45 Mini Excavator Service Manual
