New Holland LB90, LB110 Backhoe Loaders Service Manual
Table of Contents – Service Manual
Foreword
- About This Manual
Section 00 – Maintenance
- Scheduled Maintenance Procedures
- Lubrication Guidelines
- Routine Inspections
Section 10 – Engine (New Holland 90 to 108 hp)
- Engine Components and Service
- Diagnostics and Repair
Section 17 – Torque Converter
- Torque Converter Service and Repair
Section 21 – Transmissions
- Transmission Components and Service
Section 25 – Front Axles
- Front Axle Service and Repair
Section 27 – Rear Axles
- Rear Axle Service and Repair
Section 33 – Brake Systems
- Brake System Components and Service
Section 35 – Hydraulic Systems
- Hydraulic System Overview and Service
Section 39 – Vehicle Chassis
- Chassis Structure and Service
Section 41 – Steering Systems
- Steering System Components and Service
Section 50 – Cab Heating and Air Conditioning
- HVAC System Service and Repair
Section 55 – Electrical System
- Electrical Components, Wiring, and Diagnostics
Section 82 – Loader Removal
- Loader Removal Procedures
Section 84 – Backhoe Removal
- Backhoe Removal Procedures
Section 88 – Dealer Kits
- Dealer Service Kits and Contents
Section 90 – Cab Parts
Cab Components and Parts Information
The Manual Preface
The Workshop Manual has been written for the repair specialist. It provides important information on carrying out repair work expertly. Please go carefully through the Workshop Manual of the backhoe loader before starting any repair work. Use the Workshop Manual as a reference book and source of information even if you are familiar with backhoe loader technology. Using the Workshop Manual, the experience construction machine mechanic can carry out any necessary repairs expertly.
Sections of the Manual
The Manual is into main groups and subgroups, and covers any previous version of the machine. Any additions or modifications which can happen at a later date are not describe in this manual. The required information can easily be found by referring to the table of contents. For reasons of clarity, some of the illustrations are presented in simplified form. Differences from the actual version are therefore possible if this adds to the clarity of the information.
Repair and Parts
Carry out any necessary repair work as soon as possible. This reduces repair costs and increases the availability of your backhoe loader When doing any work on the backhoe loader, always observe the instructions given in the Workshop Manual. Extensive works not described in the New Holland Manual will gladly be executed for you by your dealer. Always use original spare parts only.
