Table of Content (Service Manual)
- Introduction
- Engine
- Power Coupling
- Front Axle System
- Rear Axle System
- Hydrostatic drive
- Brakes and controls
- Hydraulic system
- Frames and ballasting
- Steering
- Wheels
- Cab climate control
- Electrical systems
- Chemical applicators
- Spraying
- Platform, cab, bodywork and decals
The Manual Preface
This Manual has been written for the repair specialist. It provides important information on carrying out repair work expertly. Please go carefully through the Workshop Manual of the Defensor before starting any repair work. Use this as a reference book and source of information even if you are familiar with Defensor technology. Using this the experience construction machine mechanic can carry out any necessary repairs expertly.
Sections of the Manual
The Manual is into main groups and subgroups, and covers any previous version of the machine. Any additions or modifications which can happen at a later date are not describe in this manual. The required information can easily be found by referring to the table of contents. For reasons of clarity, some of the illustrations are present in simplified form. Differences from the actual version of this manual are therefore possible if this adds to the clarity of the information.
Repair and Parts
Carry out any necessary repair work as soon as possible. This reduces repair costs and increases the availability of your Defensor When doing any work on the loader, always observe the instructions given in the Workshop Manual. Extensive works not described in this Workshop Manual will gladly be executed for you by your dealer. Always use original spare parts only.
